iDOL 44R-33, 100642, 20-280VAC/DC

€103.00

€92.70 Save 10%

cena netto Lowest price within 30 days before promotion: €92.70

Reference iDOL 44R-33, 100642, 20-280VAC/DC

iDOL 44R-33 is a capacitive relay sensor for detection of feed, grain and solids. Supply voltage: 20~280V AC/DC. Diameter 30mm (1 3/16"), smooth housing. iDOL 44R is the future of feed sensors, featuring setup and adjustment of parameters and settings through a wireless interface and SmartAdjust companion app.

Description

DOL SENSORS -LEAFLET

Technical user guide iDOL 44R-33R

Technische Bedienungsanleitung iDOL 44R-33

Technical info iDOL 44R-33

Technische info iDOL 44R-33

MODERN

iDOL 44R-33 is the future of feed sensors, featuring setup and adjustment of parameters and settings through a wireless interface and SmartAdjust companion app. The app allows for more parameters to be adapted to the individual need of the user, compared to a traditional sensor. Download the programming app from Google App Store, search for SmartAdjust or use QR code below:

IMMUNITY TO NOISE

iDOL 44R-33 has high immunity to noise from electric communication (e.g. mobile phones) and transients (e.g. from motors and contactors). The IP69K protection class offers the highest protection against water and other liquids, e.g. during the cleaning of livestock houses.

PARAMETERS

The SmartAdjust app allows you to easily edit sensor parameters:

- SENSITIVITY in the range: 0-15mm

- ON Delay (Delayed connection) in the range: 0- 3600 sec. (from 0 to 1 hour). This function is useful for the full level sensor.

- OFF Delay (Delayed disconnection) in the range: 0- 3600 sec. (from 0 to 1 hour). This function is useful for the empty level sensor.

By setting the ON Delay and OFF Delay to "0", the sensor will operate without any delay.

At your reguest, we can prepare the sensor in any configuration.

TYPICAL APPLICATIONS

A capacitive relay sensor is typically used as empty, full and level indicator in tanks, silos and containers. The powerful integrated relay means that it can control many functions directly.

The iDOL 44R series of capacitive relay sensors from dol-sensors are sturdy andeasy to operate. A mobile app makes it easy to adjust several product parameters, depending on the model.

A red LED clearly indicates the current status of the relay sensor.
iDOL 44R-33 is made in a ø30 mm smooth designmounted in a PG36/M40 gland.

RELIABILITY

The use of electronic rather than mechanic switches ensures a unique reliability, particularly as the electronics are completely encapsulated in special plastic, which provides maximum protection against humidity and other external influences in harsh environments. The sensor is also CE, C-UL and UL approved and has a high immunity to noise from electric communication (i.e. from a mobile phone) and transients (i.e. from motors and contactors). This makes the sensor very reliable.

IP Protection

The capacitive iDOL 44R-33 sensor is made in a sealed plastic housing, the protection degree of which is IP69K.

	description
Code	iDOL 44R-33 20-280V AC/DC
Index	100642
Manufacturer	DOL SENSORS / DENMARK
Supply Voltage	20-280VAC/DC 47-63Hz
Safety	Relay switches and supply voltage are galvanically separated. Test voltage 4 kV AC
Distance of activation (Sn)	0-15 mm adjustable from app SmartAdjust
ON Delay	0-3600 sec (from 0 to1 hour), adjustable from app SmartAdjust
OFF Delay	0-3600 sec (from 0 to 1 hour), adjustable from app SmartAdjust
Output	Relay CO
Relay switch max. power	Resistive load: 5A/250V
	Inductive load: 2A/250A
	5A/30 VDC
Protection Class	IP69K
Surrounding temperature, operation:	-20 °C …+ 70 °C (-4 °F - +158 °F)
Surrounding temperature, storage:	-30 °C …+ 80 °C (-22 °F - +176 °F)
LED indicator	red LED
Cable	2 m (6.6 feet) 5 x 0.5 mm2 (5 x AWG20)
Diameter	30 mm (1 3/16")
Length	138 mm (5 7/16")
Weight incl. cable	290 g (10.2oz)
Custom Tariff Number	8536-50-80
