MT8072iP (V2e)
Human Machine Interface (HMI) MT8072iP (V2e):
- touch screen, TFT color LCD
- 7.0" wide-screen size (800x480)
- ethernet, 10/100 base-T x 1
- COM1:RS-232,COM2:RS-485 2W/4W
- free tool software EasyBuilder Pro
Description
FEATURES:
| Display | Display | 7,0" TFT LCD |
| Resolution (px) | 800x480 | |
| Brightness (cd/m2) | 450 | |
| Contrast Ratio | 500:1 | |
| Backlight Type | LED | |
| Backlight Life Time | >30000 hrs. | |
| Colors | 16,7M | |
| Touch Panel | Type | 4-wire Resistive Type |
| Accuracy | Active Area Length(X)±2%, Width(Y)±2% | |
| Memory | Flash (MB) | 128 |
| RAM (MB) | 128 | |
| Processor | Type | Dual-core RISC |
| I/O Port | SD slot | N/A |
| USB Host | USB 2.0 x 1 | |
| USB Client | N/A | |
| Ethernet | 10/100 base-T x 1 | |
| COM port | COM1:RS-232,COM2:RS-485 2W/4W | |
| RTC | Real time Clock | Built-in (CR2032 3V lithium battery) |
| Power | Input power | 24 VDC ± 20% |
| Power consumption | 450mA @ 24 V | |
| Power Isolation | Built-in | |
| Voltage resistance | 500 VAC (1 min.) | |
| Isolation Resistance | Exceed 50M Ohm at 500VDC | |
| Vibration Endurance | 10 to 25 Hz (X,Y,Z direction 2G 30 minutes) |
|
| Specification | Enclosure | Plastik |
| Dimensions WxHxD | 200.4 x 146.5 x 34mm | |
| Panel Cutout | 192 x 138mm | |
| Weight | Approx. 0,52 kg | |
| Environment | Protection Structure | NEMA4 / IP65 Compliant Front Panel |
| Storage temperature | -20 ~ 60 ° C (-4°~ 140 ° F) | |
| Operating temperature | 0 ~ 50 ° C (32°~ 122 ° F) | |
| Relative Humidity | 10 % - 90 % @ 40° C (non-condensing) | |
| Certification | CE | CE |
| Software | Free | EasyBuilder Pro |
| Tariff | Custom Tariff number | 85371091 |
