Description
SUSOL Series LS Electric
Low voltage circuit breakers LS Electric
Wyłączniki kompaktowe LS Electric
- Circuit breaker,
- Rated current, In: 40 A,
- No. of poles: 3 p,
- Adjustable rated current setting (Ir)
- Adjustable short time delay current setting (Isd),
- Adjustable time delay setting (tsd)
- Alarm LED 90% Ir: ON, 106% Ir or more: ON-OFF
- Test connector
- Rated operational voltage, Ue: AC: 690 V; DC 500 V,
- Rated impulse withstand voltage, Uimp: 8 kV,
- Rated ultimate short-circuit breaking capacity, Icu AC 50/60 Hz:
220/240 V - 100 kA
380/415 V - 50 kA
440/460 V - 50 kA
480/500 V - 42 kA
660/690 V - 10 kA
- Rated ultimate short-circuit breaking capacity, Icu DC:
250 V - 50 kA
500 V - 50 kA
- Rated service breaking capacity, Ics: 100 %Icu
- Category of utilization: A
- Isolation behavior: YES
- Norm: IEC60947-2
- Front and rear connection: fixed
- Front and rear connection: plug-in
- Mechanical life: 25000 operations
- Electrical live @ 415 VAC: 10000 operations
- Basic dimensions W x H x D: 105 x 160 x 86 mm
Product Details
TS100N ETS23 40A 3P
