MOD-8AO - 8 analogue universal outputs

€153.00
cena netto
MOD-8AO
  • OUTPUT: 8 universal analogue outputs;
  • INPUT: RS485 - Modbus Slave (ASCII, RTU);
  • Up to 128 modules on RS485 network;
  • Mounting on a DIN rail;
  • voltage output: 0~10VDC;
  • current output: 0~20mA; 4~20mA;
  • Individual channel configuration;
  • Comfortable connectors for cables (up to 2.5 mm2);
  • Configuration: Modbus Configurator; (free)
  • 2 years guarantee;
  • Made in Poland
Quantity

Description

User manual MOD-8AO

Dokumentacja MOD-8AO (User manual - Polish version)

Current output configuration MOD-8AO

Konfiguracja wyjścia prądowego MOD-8AO

Voltage output configuration MOD-8AO

Konfiguracja wyjścia napięciowego MOD-8AO

Moduły MODBUS-deklaracja zgodność ze znakiem CE (Declaration of conformity with the CE mark - Polish version)

Declaration of Conformity CE - SLIM modules

IO Configurator - download

  • OUTPUT: 8 universal analogue outputs
  • INPUT: RS485 - Modbus Slave (ASCII, RTU)
  • Supply voltage: 10-38VDC; 10-28VAC
  • Up to 128 modules on RS485 network
  • Mounting on a DIN rail
  • voltage output: 0~10VDC
  • current output: 0~20mA; 4~20mA
  • Individual channel configuration
  • 2 x configurable NPN outputs to 500mA, switched remotely or automatically when the set value is exceeded
  • Equipped with set of LEDs used to indicate the status of outputs useful for diagnostic purposes and helping to find errors
  • Comfortable connectors for cables (up to 2.5 mm2)
  • Configuration: Modbus Configurator (free)
  • Custom Tariff Number: 8543-70-90-99
  • 2 years guarantee
  • Made in Poland

The MOD-8AO module has a set of 8 analogue outputs that could work as a current output (0-20mA or 4-20mA) or as a voltage output (0-10V). Each channel can be individually configured. Setting the output curent or voltage value is done via RS485 (Modbus protocol), so you can easily integrate the module with popular PLCs, HMI or PC equipped with the appropriate adapter.

The module MOD-8AO communicates with all commercially available PLCs and other devices that support popular Modbus Master protocol.

This module is connected to the RS485 bus with twisted-pair wire. Communication is via MODBUS RTU or MODBUS ASCII. The use of 32-bit ARM core processor provides fast processing and quick communication. The baud rate is configurable from 2400 to 115200.

The module is designed for mounting on a DIN rail in accordance with DIN EN 5002. The module is equipped with a set of LEDs used to indicate the status of outputs useful for diagnostic purposes and helping to find errors.

Module configuration is done via USB by using a dedicated computer program - Modbus Configurator (free). You can also change the parameters using the MODBUS protocol.

SLIM series modules can be easily combined with each other through joint Quick Connector. Just connect the power and RS485 for the first module. Using a tape MOD-QC both values will be passed to the next module.

Available accessories:

Connection tape: MOD-QC
Programming cable 1,0m: mini USB-1
